100x Pre-Insulated Pin Terminals – Blue PVC, Copper/Tin (1.50 - 2.50mm² Wire, 9.5mm Stud) CTIE T2P9.5

100x Pre-Insulated Pin Terminals – Blue PVC, Copper/Tin (1.50 - 2.50mm² Wire, 9.5mm Stud)

T2P9.5

General Information:

• Type: High-quality Pre-Insulated Pin Terminal for reliable electrical connections.
• Insulation Colour: Features a Blue insulation sleeve, commonly indicating wire size compatibility for 1.5-2.5mm² applications.

Product Details:

• Wire Size Compatibility: Designed for use with wire sizes ranging from 1.5 mm² to 2.5 mm².
• Stud Size: Features a 9.5mm stud, ideal for various terminal block and connector applications.
• Pack Quantity: Supplied in convenient packs of 100 pieces.

Technical Specifications:

• Material (Insulation): Durable PVC.
• Material (Terminal): Electro-tin plated Copper.
• Material (Plating): Tin plating for enhanced corrosion resistance and conductivity.
• Maximum Temperature: Rated for a maximum temperature of +75°C.
• Maximum Electrical Rating: 600V
• Compliance: RoHS Compliant, ensuring environmental safety standards are met.

Another Top Quality Product From CTIE (A UK Company)
